Dry and concentrate aqueous or non-aggressive samples with speed and cost-efficiency using Thermo Scientific SPD2010 Integrated SpeedVac Concentrator. This quiet system is designed for fast installation, programming, and operation. It is ideal for drying DNA/RNA precipitates in plates or tubes, PCR samples in water/ethanol or isopropanol, and drying oligonucleotides.
Features:
- Plug and play installation: no tubing connections with concentrator, oil-free vacuum pump and cold trap all in one unit
- Ease of operation: intuitive one program digital display allows you to program heat, run time, ramp rate and vacuum level
- Standard rotors hold two or more tube sizes
- Ramp rate and vacuum control enhance mixed solvent evaporation and eliminate solvent bumping
- Oil-free vacuum pumps is virtually maintenance free
- PTFE coated chamber protects the chamber from corrosion, while making cleaning easy
- Faster sample drying provided with radiant cover
- Reduced-length vapor path from concentrator to refrigerated vapor trap accelerates evaporation
- Rotors fit a wide variety of sample formats
- SPD1010 holds 0.5 to 100mL flasks, and shallow-well microplates SPD2010 holds 1.5 to 500mL flasks, and shallow-well and deep-well microplates
Specifications:
| Chamber Material | PTFE coated aluminum |
|---|---|
| Temperature Range (Metric) | Adjustable, 45° to 80°C |
| Capacity (Metric) | 4L |
| Displacement | 30L/min. at 50Hz |
| Hertz | 50Hz |
| Item Description | SPD2010 DNA; 230V 50Hz |
| Max. Vacuum | 7 torr (9 mbar) |
| Memory | 1 program |
| Operating Temperature | -50°C |
| Pump Type | ETFE oil-free diaphragm pump |
| Ramp Rate | 1 to 5 |
| Vacuum Control | 30 to 5.1 torr |
| Voltage | 230V |
| Electrical Requirements | 230V 50Hz |
| Holds | 1.5 to 500mL flasks and shallow-well and deep-well microplates |
