Record accurate and reliable pH, ion concentration, mV, ORP and temperature measurements with the Thermo Scientific™ Orion Star A214 pH and ISE Benchtop Meter, ideal for a wide range of applications and advanced pH or ion analysis in the lab. Perform up to 5 point pH and ISE calibrations, log up to 2000 data point sets with time / date stamp and easily transfer calibration and data logs via USB or RS232 to a printer or computer with free downloadable Orion Star Com software. Use the included electrode stand to easily place sensors in samples and simplify storage to minimize breakage.
Features:
- Soft keys update for easy selection.
- Samples can be mixed without a stir plate with direct control of the Orion Star stirrer probe (096019, sold separately).
- Included electrode arm and newly designed probe holder make it easier to maintain and place probes into samples.
- Meter works with almost every AC power source with the included universal power adapter or with four AA batteries (sold separately) to run the meter on DC power.
- IP54-rated housing handles splashes and is wall-mountable if table space is a problem.
- Meter comes with a three-year replacement warranty.
Specifications:
| Resolution (pH) | 0.1, 0.01, 0.001pH |
| Range (mV) | ±2000.0mV |
| Range (ORP) | ±2000.0mV |
| Accuracy (mV) | ±0.2 mV or ±0.05% of reading whichever is greater |
| Resolution (ISE) | 0.0001 minimum, 1 to 3 significant digits (user selectable) |
| Advanced ISE Functions | Segmented (point-to-point) slope, non-linear selectable auto-blank, low concentration range stability |
| Calibration | pH with calibration editing option, ion concentration (ISE) with calibration editing option, relative mV (RmV), ORP and temperature |
| Calibration Points (ISE) | 1 to 5 |
| Range (Temperature) | -5.0° to 105.0° C, 22.0° to 221.0° F |
| Accuracy (Temperature) | ±0.1°C |
| Temperature Probe Calibration | 1 point temperature offset calibration |
| Display Type | Graphic LCD with backlight |
| Keypad | Comprehensive with menu-specific function keys and dual purpose scroll/shortcut keys |
| Stability | Selectable fast, medium, slow or Smart Stability setting; Selectable off or Automatic Smart averaging setting |
| Data Points | 2000 with date and time stamp |
| Memory | Non-volatile memory preserves data log, calibration log and meter settings |
| Methods | 10 per channel with password protection |
| Inputs | BNC (pH, ORP or ion selective electrode), pin-tip (reference electrode), 8 pin MiniDIN (ATC temperature probe), stirrer input (stirrer probe) |
| Power Supply | Universal AC adapter (included) or 4 AA batteries (sold separately) |
| Battery Type | Four AA (sold separately) |
| IP Rating | IP-54 |
| Temperature (English) Operating | 41° to 113°F (ambient) |
| Relative Humidity Range | 5 to 85 %, non-condensing |
| Weight (Metric) | 0.9kg |
| Model | Orion Star A214 pH/ISE/mV/RmV/ORP/Temperature Benchtop Meter |
| Range (pH) | -2.000 to 20.000pH |
| Accuracy (pH) | ±0.002pH |
| Range (Relative mV) | ±2000.0mV |
| Resolution (mV) | 0.1mV |
| Range (ISE) | 0.0001 to 19900 with selectable units of ppm, Molar, mg/L, %, ppb or none |
| Accuracy (ISE) | ±0.2 mV or ±0.05% of reading whichever is greater |
| Isopotential Point | 7.000pH |
| Calibration Points (pH) | 1 to 5 |
| Calibration Points | 1 point relative mV (RmV) mode, 1 point ORP mode |
| Resolution (Temperature) | 0.1°C, 0.1°F |
| Temperature Selection | Manual or automatic with ATC temperature probe |
| Channels | 1 |
| Backlight Option | Yes, selectable |
| Measurement Modes | pH, mV, relative mV (RmV), ORP or ion concentration (ISE) with temperature |
| Data Management Details | Transfer single, range or all data points to printer or computer |
| Log Function Type | Automatic data logging with Auto-Read and Timed measure modes; manual data logging with Continuous measure mode |
| Alarm Output | High/low limit alarm, calibration due alarm |
| Languages | English, Spanish, French, Italian, German and Chinese; Portuguese and Korean available with software update |
| Outputs | USB, RS232 |
| AC Adapter | Universal 50-60 Hz, 100-240 VAC power adapter (Cat. No. 1010003) |
| Battery Life | 800 hours |
| Certifications/Compliance | CE, TUV 3-1, FCC Class A |
| Temperature (Metric) Operating | 5° to 45° C (ambient) |
| Dimensions (L x W x H) | 24cm x 18cm x 11cm (9.5 in. x 7.1 in. x 4.3 in.) |
| Weight (English) | 2 lb. |
