Thermo Scientific Forma Series II Water-Jacketed CO2 Incubators provide precise CO2 control, unsurpassed temperature stability and superior parameter recovery characteristics, with continuous contamination control technology. They provide an environment for the growth of microbiological samples or mammalian cells for research (FDA Class 1), and IVF and other regulated cell therapy applications (FDA Class 2).
Performance
- Validatable in-chamber HEPA air filtration system maintains Class 100 air quality
- Enviro-Scan microprocessor control
- Setpoints and calibration: Temperature, overtemperature, CO2, O2
- Audio/visual alarms with alarm silence
- Configure Audible On/Off, Access Code, HEPA Filter Change Reminder, RS-485 Interface, Automatic Tank Selector, Audible/Visual Alarms, Display Temp/RH (selectable), Display CO2/O2 (selectable)
Construction
- Durable triple-wall cabinet construction ensures optimal temperature uniformity
- Exclusive, heated dual pane inner glass door minimizes condensation, enables faster temperature recovery
- CFC-free foam insulated outer door (field-reversible)
- Magnetic outer door gasket
- Accessory outlet
- Alarm contacts (NO, NC, COM)
Capacity | 6.5 cu. ft. |
Data Outputs | Optional 4-20mA |
Capacity (Metric) | 184 L |
CO2 Concentration Range | 0 to 20% |
Lighting | LED |
Oxygen Control | 1 to 21% |
Temperature Range (Metric) | Ambient +5°C to 50°C |
Humidity Source | Water Pan |
Weight (English) | 365 lb. |
Voltage | 120 V |
