The System II Liquid to Liquid/Liquid Recirculator uses building recirculating or tap water as the secondary cooling medium to remove heat from the cooling fluid in the closed circulation loop.
The unit consists of a heat exchanger, recirculation pump, stainless steel reservoir, and a temperature controller.
The System II is available with two different plumbing configurations: single circulation loop (this unit is a single circulation, turbine pump system), and dual circulation loop.
The single circulation loop unit has either two positive displacement pumps (PD-2) or a single turbine pump (TU-3), plumbed to a single inlet and outlet. The front panel switches and gauges correspond to this loop.
The dual circulation loop unit has two positive displacement pumps (PD-2), each plumbed to a separate inlet and outlet (A and B). The front panel switches and gauges labeled A, correspond with loop A. Front panel switches and gauges labeled B, correspond with loop B.
Specifications:
Temperature Range: +10°C to +30°C
Temperature Stability1: ±1.0°C
Reservoir Volume: 1.75 Gallons (6.6 liters)
Unit Dimensions: 30-1/8\” H x 16-1/4\” W x 20-1/8\” D (76.5 x 41.3 x 51.1 cm)
Pump Type: TU-3, Turbine, 6 gpm at 40 PSI
