The AriaDx Real-Time PCR system is a fully integrated qPCR solution for amplification, detection, and data analysis, combining a novel thermal cycler, an advanced optical system with LED excitation source, and comprehensive data analysis software.
AriaDx has a closed-tube PCR detection format and can be used with many fluorescence detection chemistries, including SYBR Green and EvaGreen dyes, and fluorogenic probe systems such as TaqMan. Functional reporting with more than 120 attributes, and built-in diagnostics assist in troubleshooting. A modular and flexible design with intuitive touch-screen interface improves ease-of-use and productivity.
Specifications
ARIA Software – Standard with Instrument | Yes |
Accuracy | ±0.2 °C |
Data Acquisition Time | <3 sec |
Detection Sources | 8 filtered photodiodes |
Dimensions (WxDxH) | 50.0 x 46.0 x 42.0cm (19.7 x 18.1 x 16.5 inches) |
Dynamic Range | 9 |
Excitation Source | 8 dye specific LEDs per optical module |
Max Optical Modules | 6 |
Maximum Block Ramp Rate | 6 °C/Sec |
Number of Peltiers | 6 |
Number of Wells | 96 |
Number of wells for multiplexing | Up to 5 targets per well |
Optical Module Types |
|
PCR Uniformity | ±0.4 °C |
Protocol Storage Count | 5GB |
Reaction Volume | 10-30 µL |
Remote Monitoring | Yes |
Sample Container Types |
|
Self-Installable Optical Modules | Yes |
Software Included | Free software including LIMS connectivity feature |
Software Upgrade Statements | Available online, no charge |
Thermal System Temperature Range | 25.0-99.9 °C |
Weight | 23 kg |
